Section 5 Remote Control by GPIB

5.1 Overview

Pattern Generator is an optional device of MG3641A/MG3642A Synthesized Signal Generator to enable automatic mea-

surement in combination with the external controller and the other measurement devices in the same way as for the other

function of the main unit.

This device complies with the IEEE (Institute of Electrical and Electric Engineers) std 488.1-1987. Besides, the software

specifications comply IEEE488.2 and SCPI (Standard Commands for Programmable Instruments).

GPIB command tree and the command detailed description of Pattern Generator is described in this chapter.

For additional descriptions, see Section 6 “Remote Control by GPIB” of the separate document “MG3641A/MG3642A

Synthesized Signal Generator Operation Manual”

5.2 Command Tree

The device message commands tree added by the Pattern Generator implementation is as follows:

: PATTern

: STATe

: STATe?

: SELect

: SELect?

: SEND

: RATE

: RATE?

: TYPE

: TYPE?

: MODE

: MODE?

5.2 Command Tree
