A-3 Test Records for Spectrum Analyzer Verification Appendix A — Test Records
A-4 PN: 10580-00324 Rev. N S412E MM
S412E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-6. Spectrum Analyzer DANL with Preamp On
Start Freq Stop Freq RBW VBW Specification
Measured Values
at 100 kHz RBW
Calculated Values
for 10 Hz RBW
10 MHz 1.6 GHz 100 kHz 1 kHz <
–147 dBm dBm dBm
(PERFORM THE FOLLOWING TESTS IF OPTION 6 IS INSTALLED)
1.6 GHz 2.4 GHz 100 kHz 1 kHz <
–147 dBm dBm dBm
2.4 GHz 4.0 GHz 100 kHz 1 kHz <
–144 dBm dBm dBm
4.0 GHz 5.0 GHz 100 kHz 1 kHz <
–140 dBm dBm dBm
5.0 GHz 6.0 GHz 100 kHz 1 kHz <
–133 dBm dBm dBm
