Appendix A — Test Records A-3 Test Records for Spectrum Analyzer Verification
S412E MM PN: 10580-00324 Rev. N A-5
S412E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-7. Spectrum Analyzer Frequency Accuracy
Frequency Specification Measured Value Deviation
1 GHz ± 120 Hz (± 120 ppb) GHz kHz
(PERFORM THE FOLLOWING TESTS IF OPTION 6 IS INSTALLED)
3.9 GHz ± 468 Hz (± 120 ppb) GHz kHz
5.9 GHz ± 708 Hz (± 120 ppb) GHz kHz
Table A-8. Spectrum Analyzer SSB Phase Noise
Offset Frequency Specification Measured Value Calculated Value
10 kHz <
–100 dBc/Hz dBc/Hz dBc/Hz
100 kHz <
–105 dBc/Hz dBc/Hz dBc/Hz
1MHz <
–115 dBc/Hz dBc/Hz dBc/Hz
Table A-9. Spectrum Analyzer Spurious Response (Second Harmonic Distortion
Frequency Specification Measured Value 2nd Harmonic Level
50.1 MHz NA dBm
100.2 MHz < –56 dBc dBm dBc
