E
DESCRIPTION OF CONTROLS AND INSTRUMENTS
Ref. Description Use/Function
inside the vehicle cab (fig. 6)
C1 Control circuit switch it connects/disconnects the control circuit of the Tail-lift (Optional)
C2 Pilot light for platform not at rest when it is on, the platform is not at rest (Optional)
on the main console (fig. 7)
C3 Key-operated switch it connects/disconnects the power supply of the Tail-lift
C4 Enabling push-button If pressed, it enables the auxiliary controls (foot, inside the vehicle, etc.) and its warning light is on
auxiliary controls/console controls once released, it enables the console controls
C5 Platform movement lever When it is actuated to the left, the platform rotates downwards
(enabled only with C5/1 pressed) When it is actuated to the right, the platform rotates upwards
When it is actuated downwards, the platform lowers
When it is actuated upwards, the platform lifts
C5/1 Control enabling push-button C5 If pressed, it enables C5 control
C7 Stabiliser lowering push-button (optional) if pressed, stabilisers are lowered
C7/1 Stabiliser lifting push-button (optional) if pressed, stabilisers are lifted
A Auxiliary control plug (optional) to be connected with the push-button panel plug (Optional)
N.B. it is strictly forbidden to replace the burnt out fuses with fuses having a greater amperage or with electrical bridge.
E
DESCRIPTION OF CONTROLS AND INSTRUMENTS
Ref. Description Use/Function
inside the vehicle cab (fig. 6)
C1 Control circuit switch it connects/disconnects the control circuit of the Tail-lift (Optional)
C2 Pilot light for platform not at rest when it is on, the platform is not at rest (Optional)
on the main console (fig. 7)
C3 Key-operated switch it connects/disconnects the power supply of the Tail-lift
C4 Enabling push-button If pressed, it enables the auxiliary controls (foot, inside the vehicle, etc.) and its warning light is on
auxiliary controls/console controls once released, it enables the console controls
C5 Platform movement lever When it is actuated to the left, the platform rotates downwards
(enabled only with C5/1 pressed) When it is actuated to the right, the platform rotates upwards
When it is actuated downwards, the platform lowers
When it is actuated upwards, the platform lifts
C5/1 Control enabling push-button C5 If pressed, it enables C5 control
C7 Stabiliser lowering push-button (optional) if pressed, stabilisers are lowered
C7/1 Stabiliser lifting push-button (optional) if pressed, stabilisers are lifted
A Auxiliary control plug (optional) to be connected with the push-button panel plug (Optional)
N.B. it is strictly forbidden to replace the burnt out fuses with fuses having a greater amperage or with electrical bridge.
