E
Ref. Description Use/Function
on the platform (optional) (fig. 8)
C8 Platform lifting push-button if pressed the platform lifts [enabled only if (C10) is pressed]
C9 Platform lowering push-button if pressed, the platform lowers [enabled only if (C10) is pressed]
C10 Enabling push-button if pressed (C8) and (C9) are enabled
on the push-button panels (optional)
(either of the auxiliary control inside the cab or of the auxiliary control) (fig. 9)
C11 Platform lifting push-button if pressed, the platform lifts
C12 Platform lowering push-button if pressed, the platforms lowers
on the wireless control push-button panel (optional) (fig. 10)
C13 Platform lifting push-button if pressed, the platform lifts
C14 Platform lowering push-button if pressed, the platforms lowers
A Signal Led will turn on when you press one of the buttons on the wireless control, indicating the functioning of the same. If the Led does not turn on
then the battery inside the wireless control must be replaced.
Note: all the above described auxiliary controls are only enabled by pressing the (C4) push-button.
E
Ref. Description Use/Function
on the platform (optional) (fig. 8)
C8 Platform lifting push-button if pressed the platform lifts [enabled only if (C10) is pressed]
C9 Platform lowering push-button if pressed, the platform lowers [enabled only if (C10) is pressed]
C10 Enabling push-button if pressed (C8) and (C9) are enabled
on the push-button panels (optional)
(either of the auxiliary control inside the cab or of the auxiliary control) (fig. 9)
C11 Platform lifting push-button if pressed, the platform lifts
C12 Platform lowering push-button if pressed, the platforms lowers
on the wireless control push-button panel (optional) (fig. 10)
C13 Platform lifting push-button if pressed, the platform lifts
C14 Platform lowering push-button if pressed, the platforms lowers
A Signal Led will turn on when you press one of the buttons on the wireless control, indicating the functioning of the same. If the Led does not turn on
then the battery inside the wireless control must be replaced.
Note: all the above described auxiliary controls are only enabled by pressing the (C4) push-button.
