Antunes VCTM-2 - Installation

®
P/N 1011436 Rev. H 02/21
6
Bun Feeder
(Mfg. No. 9210913 only)
Butter Wheel
(Mfg. No. 9210914 only)
Pan
(Mfg. No. 9210914 only)
Release Sheet
Cleated Belt Wraps
(Mfg. No. 9210914 &
9210916 ONLY)
Rear Conveyor
Cover Assembly
Front Conveyor
Cover Assembly
Bun Chute
Platen
Bun Chute Assembly
connected over the rear
Conveyor Cover Hinge
Figure 3. Components
