Service Manual AOC N950SW
17
4.电气方框图
4.1 LCD 整机方框图
4.2 Panel 方框图
DC-AC inverter
AC-DC(5V/16V)
Power Board
Main Board
715G4737-M01
Key board
2-FCC backlight
Panel1366*768
LVDS
AC supply
90V-264V
Monitor Block Diagram
PC- VGA
/DDC
Input signal
