Service Manual AOC N950SW
42
8.故障处理流程
8.1 主板
无供电
无供电
按下电源键看画面是否正常
重新插插头然后检查 AC:100-240V 是否正常?
检查 U404 Vout=3V
检查适配器及升压板部分和交流电源输入
检查 X401 晶振是否正常
检查或更换 CN404,U404
检查 U401
更换 X401
OK
OK
OK
NG
NG
NG
NG
更换 U401 更新软体
NG
