AOC N950SW User Manual

Service Manual AOC N950SW
4
1.显示器规格
1.1 技术规格
Monitor Model AOC N950SW
LCD Panel
Driving system TFT Color LCD
Active Display Area
40 cm for LCD performance, 20 cm for LCD
failures409.8H*230.4V
Pixel Pitch 0.2835 mm×0.2835mm
Input
Video
R,G,B Analog Interface，75ohm,0.7V
Separate Sync. H/V TTL
H-Frequency 30kHz—81kHz
V-Frequency 56Hz--75Hz
Input Connector D-Sub 15pin
Display Colors 16.7M Colors
Dot Clock 136.75MHz
Max. Resolution 1366x768, 60 Hz
Plug & Play VESA DDC2B DDC/CI
Power Consumption
ON Mode <25W
Power Saving Mode <1W
Switch OFF <0.5W
Power Source
: 90V ~ 240 V
: 50HZ±, 60HZ±
Max supply current
Environmental Operating Temp: 0° to 40°C
Considerations Storage Temp.: -20° to 60°C
Operating Humidity : 8% to 80%
Dimensions(including stand)
456.75(W)x375.5(H)x149.8 (D)mm
Weight (N. W.): 3.50kg
Safety FCC B CE mark CCC IEC950CB etc.
