Service Manual AOC N950SW
48
9.料件清单
注意: 以下料件信息仅供参考，如有变更，恕不另行通知，请到 http://cs.tpv.com.cn
T8BMR9NYAGA1NNJ
获取最新信息。
点位 组件号 对象描述
数量
(CUn)
052G 1207 A ALUMINIUM TAPE 1
052G 1211 B
Conductive Tape 85mm *40mm *0.09mm (单导)
2
E08902 089G 725HAA DB D-SUB CABLE 1
E08901 089G414A15N HL POWER CORD 1500MM China Reg 1
0M1G1030 6120 SCREW M3X6 5
0M1G1030 8120 SCREW 1
0M1G3030 6 47 CR3 SCREW 1
0Q1G 140 12120 SCREW 4X12 1
0Q1G 330 8120 SCREW 3X8mm 1
E750 750GLM185B1722N000 LCD M185B1-L07 C2/C6(66) NB CMI 2nd source
E750 750GLM185B1732N000 LCD M185B1-L07 C2/C5(C6) NB CMI 1
756GJBCB AA004 MCU ASS'Y main board CBPCBR9A1J1
U402 056G2233501 FLASH MX25L2026DM1I-12G 2Mb SOP-8 1
SMTCR-U402 100GARM8000B11 AOC_N950Sw_RTD2270LW_CMI_M185B1L07
U401 056G 562431 SCALER RTD2270LW-CG LQFP-64 1
CBPCBR9A1J1 CONVERSION G4737-M01-000-0040-1-110311 1
A15G1587101 HINGE PLATE FOR 50TH 2nd source
A33G1181ABJ 1L0100 FUNCTION BUTTON FOR 50TH 1
A33G1182 1 1L0100 POWER LENS FOR 50TH 1
A33G1183ABJ 1L0100 STAND TOP FOR 50TH 18.5W 1
A33G1184ABJ 1L0100 HINGE COVER FOR 50TH 18.5W 1
A34G2528AEDA1B0130 BEZEL FOR 50TH 18.5W 1
A34G2529ABJ 5B0130 REAR COVER FOR 50TH 18.5W 1
A34G2530ABJ 1B0100 STAND COVER 1
A34G2531AED 1B0130 BASE FOR 50TH 18.5W 1
A37G0241011 HINGE FOR 50TH 18.5W 1
AM1G1740 10125 SCREW 4
CN408 033G3802 6B Y L WAFER 1
CN404 033G3802 9B Y L CONN 2.0 9P 1
040G 45762412B CBPC LABEL 1
CN101 088G 35315FVCL D-SUB CONN 15P V/T 10.5mm WITH SCREW 1
X401 093G 22 53 YC Crystal 14.31818MHz/32PF 49U/S YC 1
CN405 311GW200C30ABL WAFER 2.0mm 2*15P 1
AIGBR9A1J1 MAIN BOARD FOR AI 1
C423 067G305M1013CB EC 100UF 20% 16V 6.3*7 1
C421 067G305M1013CB EC 100UF 20% 16V 6.3*7 1
C427 067G305M1013CB EC 100UF 20% 16V 6.3*7 1
C426 067G305M1013CB EC 100UF 20% 16V 6.3*7 1
SMTCBR9A1J1 MAIN BOARD FOR SMT 1
U406 056G 563149 IC G903T63UF 0.6A/3.3V SOT-223 1
U103 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L 1
U102 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L 1
U403 056G1133 56 M24C16-WMN6TP 1
U405 056G1133531 EEPROM FM24C02A-SO-T-G 2K SOP-8 1
U402 056G2233501 FLASH MX25L2026DM1I-12G 2Mb SOP-8 1
Q404 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC 1
