8. Test Button
9. Power Button
10. Command Indicator
11. Master Button
12. Model Control Buttons
(<I> Turn on, <O> Turn off)
13. Beeper Button
14. Fast Mode Switch Button
(FAST/NORMAL)
15. Mode Adjustment Button
(Figure 1-b)
16. USB Port
17. In Port (3.5mm)
18. Out Port (3.5mm)
19. Mounting Foot Lock Lever
20. Hot Shoe Mounting Foot
• 9 •
16
17
18
19
20
