AODELAN E3+ - Parts

6
I. Parts
1. <LINK> indication light: Radio
transmission conrmation lamp
2. LCD panel
3. Function Button 3
4. Function Button 2
5. Function Button 1
6. <MODE>: Flash mode button
7. <
>: Charge lamp/Test ash
button
8. <
>: Select/Set button
9. <
>: Select dial
10. Mounting foot lock lever
11. Battery compartment cover
12. Function button 4
13. <
>: Linked shooting button
14. Power button
15.
Flash exposure conrmation lamp
16. Lock-rel ease button
17. USB port
18. Remote release terminal
19. Contacts
20. Mounting foot
21. Locking pin
22. AF assist light
1
5
6
7
8
9
10
2
3
4
11
12
13
14
15
19
16
17
18
20
21
22
