message at the LCD display.
When this indicator blinks, it
indicates that the LIMP HOME mode
is activated.
Refer to TROUBLESHOOTING
section for more details.
(7) Neutral position indicator
(8) Trip meter indicator
(9) Time indicator
(10) 2WD/4WD indicator
When this indicator is ON, it
indicates the 4WD system is
activated.
(11) Engine Temperature
When this indicator light is ON, it
indicates the engine is overheating. If
engine overheats, stop engine. See
an authorized AODES USA Pick Up
UTV dealer. Do not use the vehicle
until repaired.
A. MODE button
Pressing the MODE (M) button will
scroll through the functions of the
main digital display.
B. SET/RESET button
Pressing the SET (S) button will
scroll through the functions of the
secondary digital display.
Supplementary instruction
Neutral (GREEN)
When lit, it indicates the transmission
is in neutral position.
Right-turning indicator
light(GREEN)
When this indicator light is flashing, it
is for turning right.
(17) Rear Differential
Switch&2WD/4WD Switch
（1）Rear Differential Switch
The Differential switch is located on
the console.
The differential switch enables
locking of rear differential.
NOTICE：The vehicle must be
stopped to engage or disengage
the differential switch. Mechanical
damage may occur if switch is
engaged or disengaged while
driving.
（2）2WD/4WD Switch
This switch selects 2 wheel drive or 4
wheel drive mode when the vehicle is
stopped and the engine is running.
