1.2 System Overview
1.2.1 Summary of Motherboard Features
● The system is designed to support Intel pro
cessors under 115 W, 3xx/5xx/6xx/820/920/930
sequence.
● The system is built with two memory slots
supporting DDR2 667/533 memory modules.
The total system memory can be expanded to
2GB.
● Provides six USB 2.0 ports.
● Supports one slim-type exible disc drive or a 7-in-1
card reader. (depending on the model selected)
● Supports one PCI Express slot.
● Supports ATA100 and SATA II drives
● Supports automatic power recovery function
1.2.2 Summary of Audio Features
● Supports Azalia Codec on-Board (Realtek ALC880 support
7.1 Channel) which provides stereo sound effects
● Provides earphone output and microphone input on front
and rear panels
1.2.3 Summary of General Input/output Ports
● One Serial port
● Parallel/printer port
● One PS/2 keyboard port
● One PS/2 mouse port
