AP Diving Ltd. APV200 Inflator Maintenance Manual
Page 12 of 30
4.6 Remove direct feed button from direct feed body
- Just pull it out.
4.7 Remove direct feed body from main body
- Shake the main body a bit, and the feed body will drop out.
4.8 Remove O-ring and mesh filter from direct feed body
- Both the O-ring and the mesh filter need to be replaced during service.
