Stages 3 and 4 can operate as heating or cooling stages.
ð Set switches # 6 and # 7 to OFF to
use both stages for cooling.
ð Set switch # 6 to ON and switch # 7
to OFF to use Stage 4 for heating
and Stage 3 for cooling.
ð Set switches # 6 and # 7 to ON to
use both stages for heating.
Note that if only one stage is used for heating, it must be Stage 4.
HEATING / COOLING OPTION
6
7
ON
n Set the selection knob to STAGE 2 — OFFSET/BANDWIDTH.
The offset is displayed, alternating with the letters "OFT".
n Press the push-button twice. The currently selected motor type
flashes.
n Use the adjustment knob to adjust the motor type to the desired value.
n Return to the Stage 2 offset display by pressing the push-button
once again.
