AP TC5-2V2SA - Controller Status Leds; Internal Switches

7
TC5-2V2SA.rev.05
TC5-2V2SA
LED MEANING
STAGE 1
TURNS ON WHEN STAGE 1 FANS ARE ON.
STAGE 2
TURNS ON WHEN STAGE 2 FANS ARE ON.
STAGE 3 /
HEATER 2
TURNS ON WHEN STAGE 3 FANS OR HEATING UNITS ARE ON.
STAGE 4 /
HEATER 1
TURNS ON WHEN STAGE 4 FANS OR HEATING UNITS ARE ON.
T
o
/MIN.SPEED
CURVE
FLASHES WHEN THE TEMPERATURE CURVE IS ACTIVATED. TURNS
ON WHEN THE MINIMUM VENTILATION SPEED CURVE IS ALSO ON.
DEF. PROBE/
ALARM
TURNS ON WHEN AN ALARM IS DETECTED. BLINKS WHEN A
DEFECTIVE PROBE IS DETECTED
LOCKED
TURNS ON WHEN THE PARAMETERS ARE LOCKED.
COMPENSATION
TURNS ON WHEN THE COMPENSATION ON STAGE 1 MINIMUM
VENTILATION SPEED IS IN EFFECT OR WHEN THE COMPENSATION
ON THE MIST STAGE IS IN EFFECT.
CONTROLLER STATUS LEDS
# OFF ON
1 UNLOCKED PARAMETERS LOCKED PARAMETERS
2 FAHRENHEIT DEGREES CELSIUS DEGREES
3 PROBE 2 DISABLED PROBE 2 ENABLED
4 PROBE 3 DISABLED PROBE 3 ENABLED
5 PROBE 4 DISABLED PROBE 4 ENABLED
6 NO HEATING STAGES HEATING
7 1 HEATER 2 HEATERS
8 CASCADING HEATERS ZONED HEATERS
9 MIST OFF MIST ON
10 RESERVED
11 RESERVED
12 RESERVED
INTERNAL SWITCHES
The internal switches are located on the inside of the front cover. When
the controller is shipped from the factory, all the switches are set to OFF.
ON
2
1
3
4 6 75
8 9
11
10
12
