4.4.1. Submenu structure in mode of waiting for start date
For submenu activation and navigation between items see chapter 4.2. Submenu navigation. Allocator self
test activation is described in chapter 4.3.1.2. Allocator self test. Radiator type selection for E-ITN 10.5x,
10.6, 10.7x is described in chapter 4.3.1.3. Setting of radiator type ( E-ITN 10.5x, 10.6, 10.7x only).
Table 4: Submenu structure in mode of waiting for start date, type E-ITN 10.4x
Allocator self-test ti
Table 5: Submenu structure in mode of waiting for start date, type E-ITN 10.5x, 10.6, 10.7x
Radiator type (e.g. 2) tot 2
Allocator self-test ti
4.5. WORKING MODE
In working mode allocator performs temperature measurement, calculates the increase of value (if
measurement conditions are met), transmits measured data, updates real-time and makes some other
actions in regular intervals.
4.5.1. Menu structure in working mode
If nothing is displayed press the button briefly.
Table 6: Submenu structure in working mode, type E-ITN 10.4x, 10.5x, 10.7x
Value for current billing period 245
Value for last billing period 458 SM
Alphanumerical code for last billing period A.0.i.h.t.
Serial number – first part -0700
Serial number – second part 0060-
* Radiator temperature 53.3°C
* Surroundings temperature – E-ITN 10.42, 10.5, 10.6, 10.7x
– E-ITN 10.41
26.7°C SM
--°C SM
* Date of billing period beginning – E-ITN 10.4x, 10.51, 10.71
– E-ITN 10.52, 10.72
u 1.12.
dF 1.
* Current date 10.12.
* Current time 12-45
Note: menu items marked as * are optional, see chapter 5.1. Allocator parameters setting.
Table 7: Submenu structure in working mode, type E-ITN 10.6
LCD test
Current date 10.12.
Start of the billing period u 1.2.
Value for last billing period 458 SM
Alphanumerical code A.0.i.h.t.
Average surroundings temperature for last billing period 23.7°C SM
Value for current billing period 245
4.5.1.1. Value for current billing period
Value for current billing period is displayed as 389 (without insignificant zeros). It is calculated from the
beginning of the current billing period.
