APC Smart-UPS 2200 Installation Guide

Smart-UPS X 2000/2200/3000 VA XL Tower/Rack-Mount 4U2
Inventory
Inspect the contents upon receipt. Notify the carrier and dealer if the unit is damaged.
Included with all models
1 pair rail cleats
8 pan head screws
1 pair tower stabilizer brackets
Use 8 flat head screws to secure tower stabilizer brackets to the UPS
1 pair rack-mount brackets
Use 8 flat head screws to secure rack-mount brackets to the UPS
Use 4 ornamental screws to secure rack-mount brackets to the rails
Install a cage nut in the rack to secure the top hole of each rack-mount
bracket in a four post rack
(1) Documentation CD
(1) PowerChute software CD
Rack-mount support brackets and hardware
Included with models that have factory installed
Network Management Cards
1 pair support
brackets
Two post racks
10 screws
Four post racks
6 screws
6 washers
Included with High Voltage (HV) models

APC Smart-UPS 2200 Specifications

General

Nominal Output Voltage	230V
Nominal Input Voltage	230V
Rack Height	2U
Input Voltage Range	160 - 286 V
Waveform Type	Sine wave
Interface Port	USB
Typical Recharge Time	3 hours
Form Factor	Rackmount/Tower
Frequency	50/60 Hz
Battery Type	Sealed Lead Acid (SLA)
