Smart-UPS X 2000/2200/3000 VA XL Tower/Rack-Mount 4U 3
Product Overview
Front panel features
Rear panel features
1 Online LED
2 Power
ON/OFF button
3 On Battery LED
4 Site Wiring Fault LED
5 Replace Battery LED
6 LCD display screen
7
UP/DOWN arrow keys
8
ENTER key
9
ESC key
1 SmartSlot 7 Controllable Outlet Group 3
2 Chassis ground screw 8 External battery pack connector
3 UPS utility power input 9 EPO connector
4 Circuit Breaker reset : Serial port
5 Controllable Outlet Group 1 ; USB port
6 Controllable Outlet Group 2
2000 VA, 120 Vac Low Voltage 3000 VA, 120 Vac Low Voltage
su0343a
APC b
y
Schneider
Electric
su0756a
GROUP 1GROUP 2
GROUP 3
su0757a
