User Manual Smart-UPS RC XLI/XLICH/XLI-CC 1000/2000/3000 VA 220/230/240 Vac Tower/Rack-Mount 4U 3
Introduction
Overview
The American Power Conversion (APC
®
) Smart-UPS
®
RC is a high performance uninterruptible power
supply (UPS) that provides protection for electronic equipment from utility power blackouts, brownouts,
sags and surges. The UPS protects electronic equipment from small utility fluctuations and large
disturbances by providing continuous on-line double converted power. The UPS provides battery backup
until utility power returns to safe levels or the batteries are fully discharged.
Unpack package contents
Read the Safety Guide before installing the UPS.
Inspect UPS upon receipt. Notify carrier and dealer if there is damage.
Packaging is recyclable; save it for reuse or dispose of it properly.
Check UPS package contents:
NOTE: The model and serial numbers are located on a small, rear panel label. For some models, an
additional label is located on the chassis under the front bezel.
Accessories
Install accessories prior to connecting power to the UPS.
Refer to the APC Web site, www.apc.com for available accessories.
Optional accessories
• External battery pack (XLBP)
• 4-post rail kit
•UPS
• Front bezel
• Front display panel
• Input power cord
• Serial cable
• Stabilizer/rack-mount brackets
• Hardware supplied listed in table below
• Literature kit containing:
– Product documentation
–Smart-UPS
®
RC User Manuals CD
– PowerChute
®
Business Edition Utility CD
– Safety information
– Warranty information
8
2
2
su0211b
Hardware supplied
Rack-mount configuration:
Pan head screws for securing rack-mount brackets to unit
Tower configuration:
Flat head screws for securing stabilizer brackets unit
Rack-mount configuration brackets
Tower configuration stabilizer brackets
