990-1062, Revision 1 04/01 4
•= 230V models: The power cord is packaged with the documentation and other cables. Plug the supplied power cord into the
inlet on the rear panel of the UPS.
•= 120V models: The power cord is permanently attached to the rear panel of the UPS.
Turn on the UPS
•= Make sure the battery is connected before turning on the UPS! Then, press the button on the front panel to power up
your UPS. This will power up connected equipment. (Make sure connected equipment is switched to the ON position.)
The UPS charges its battery when it is connected to utility power. The battery charges fully during the first four
hours of normal operation. Do not expect full run time during this initial charge period.
The unit performs a self-test automatically when turned on and every two weeks thereafter (by default). Refer to User Config-
urable Items below for details on changing the default interval.
120V Models: Check the site wiring fault indicator located on the rear panel. It lights up if the UPS is plugged into an
improperly wired AC power outlet. Wiring faults detected include missing ground, hot-neutral polarity reversal, and
overloaded neutral circuit.
If the UPS indicates a site wiring fault, get a qualified electrician to correct the building wiring.
Optional Accessories
Add any optional accessories. See the documentation accompanying the accessory for details.
ACCESSORIES
If the UPS is equipped with an accessory slot, visit the APC web site, www.apc.com, for available accessories.
If a standard accessory (such as an SNMP card) is installed on this UPS, see the Utility CD for user documentation.
For additional computer system security, install PowerChutePlus
®
Smart-UPS monitoring software. It provides automatic unat-
tended shutdown capabilities on most major network operating systems.
DISCONNECTING THE BATTERY FOR TRANSPORT
Always DISCONNECT THE BATTERY before shipping in compliance with U.S. Department of Transpor-
tation (DOT) regulations. The battery may remain in the UPS; it does not have to be removed.
1. Shut down and disconnect any equipment attached to the UPS.
2. Disconnect the UPS from the power supply.
3. Unplug the battery connector. Refer to Connect the Battery on the previous page.
4. For shipping instructions and to obtain appropriate packing materials contact APC at the web site,
www.apc.com/support/contact
.
