Smart-UPS 750/1000/1500/2200/3000 VA 100/120/230 Vac 500 VA 100 Vac Tower6
Advanced menus
The Advanced menus provide additional options for the UPS and are available only if the display
interface is configured to use the Advanced menus.
Menu General Functions
Status
View detailed UPS information:
• Operating Mode
• Efficiency
• Load Power
• Load VA
• Load Amps
• Load Energy
• Battery Charge state
• Estimated Runtime
• Battery Voltage
•Battery Temp
• Input
• Output
• Last Transfer
• Last UPS Self Test
• Outlet Group 1 (if Switched Outlet is available)
• NMC IP Address (if NMC is available)
Configuration
Configure advanced UPS settings:
• Language
• Local Power Quality
• Menu Type
•Audible Alarm
• Display (Auto Dim, Auto Off, Always On)
• Sensitivity
• Low Transfer
• High Transfer
• Low Battery Warning
• Auto Self Test
• Battery Install Date
• Reset Energy Meter
• Enter Setup Wizard
• Firmware Update (standby mode)
• Reset to Factory Default
• Config Main Group Outlets
• Config Group 1 Outlets (if Switched Outlet is
available)
• Config NMC (if NMC is available)
Control
Control the Main and Switched Outlet Group to turn on, turn off, shutdown, or reboot.
Test & Diags
Perform UPS test and diagnostic functions:
• UPS Self Test
• UPS Alarms Test
• Calibration Test
Log
View the event and error logs for information about UPS events and faults that have occurred.
About
View UPS information:
• UPS Model
• UPS Part No.
• UPS Serial No.
• UPS Manufacture Date
• Battery Part No.
• Battery Install Date
• Replace Battery by
• UPS Firmware 1
• UPS Firmware 2
• UPS Firmware 3
• UPS Firmware 4
• NMC Model No.*
• NMC Serial No.*
• NMC Hardware Version*
• NMC Manufacture Date*
•NMC MAC Address*
• SmartSlot FW 1*
• SmartSlot FW 2*
• SmartSlot FW 3*
*If NMC is available
