Apeks 2000PSI THE DUPLEX - 2 System Overview

Apeks Supercritical The Duplex™ Operation Manual
6
Revision Date 8/28/2018
2. System Overview
The Duplex™ Diaphragm Compressor
Separator Chiller
Extractor Chiller
Extractor Vessel Stand
Separator Vessel Stand
Main Control
Enclosure
HMI
Fork Pockets
