- 29 -
9 USB communication
9.1 Install Software
This instrument uses the PC-Link 910 communication software, and the communication port is USB.
Copy the PC-Link 910 program files to the computer from the flash drive, connect the USB
communication cable to the PC socket of the meter and the computer’s USB port. The software will
be automatically open. The instrument and the computer will be automatically connected, and
will show up on top of the display. If manual data logger is selected, press , data will be
uploaded to the computer, if auto. timing data logger is selected, press , data will be uploaded
to the computer by the certain timing you set. All the data uploaded to the computer will not be saved
in the meter. Auto-timing data logger will generate a measurement curve in PC-Link software as
shown in Diagram-13.
9.2 Software Interface
Diagram-13
Meter serial number
Computer connection icon
Data area
Data stored in meter
Operation keys
9.3 Operation Keys of PC-Link
Refresh When the meter and the computer are not connected, press the button to connect again.
Clear — Clear the data.
