10.4 E1608 Echo Send Applications
Echo Send Master:
• Turn the Echo Send ON
• Set the level to unity gain
• The Echo Send is fed by the corresponding Auxiliary Bus
• The Echo Send output is fed to the Echo Sends Output connector
Mix Input:
• Connect the output of the desired device (effects unit, recorder, DAW, etc.) to the Echo
Send External Input
• Engage the EXT IN
• Turn the Echo Send ON
• Set the Echo Send level to unity gain
• The Echo Send is fed by the External Input and the corresponding Auxiliary Bus
o Do not use the corresponding channel Echo sends if an isolated input is desired
• Press the MIX button on the corresponding Echo Return
• The Echo Send output is fed to the Echo Return and the Echo Sends Output connector
• Assign the Echo Return to the Program Bus and/or Summing Buses as needed
• Engage the PAN button if panning is needed
• Set the Echo Return level as desired
Audio Sub-group Master:
• Use channel Echo sends to feed the channels to be grouped to the desired Auxiliary
Buses
o It might be desirable to de-assign these channels from the Program Bus
• Turn the Echo Send ON
• Set the Echo Send level to unity gain
• The Echo Send is fed by the corresponding Auxiliary Bus
• Press the MIX button on the corresponding Echo Return
• The Echo Send output is fed to the Echo Return and the Echo Sends Output connector
• Assign the Echo Return to the Program Bus and/or Summing Buses as needed
• Engage the PAN button if panning is needed
• Set the Echo Return level as desired
Aux Send Multichannel Mix Output Master (LCRS, 5.1, 5.1EX, 7.1):
• Use the Program Bus for the Left and Right channels
• Select four channel Echo/Aux Sends for use as Center, Left Surround, Right Surround,
and LFE channels
o Using a stereo aux send for the Left and Right Surround channels is suggested
o Using a mono aux send for the Center and LFE channels is suggested
• Make sure the PRE buttons are not engaged if you want the send to follow the Fader
• Turn the selected channel Aux Sends ON and set the levels to unity gain or as needed
• Use the channel fader to adjust the contribution to the assigned 5.1 mix channels
• Turn ON the selected Echo Send modules
• Set the Echo Send level to unity gain
• The Echo Send module is fed by the corresponding Auxiliary Bus
• The L/R mix outputs are fed to the L/R Program Output connectors
• The Ls, Rs, C, and LFE mix outputs are fed to the Echo Sends Output connector
• Use addition Aux Sends if additional mix outputs are needed
