10.6 168B Summing Bus Sub-master Applications
Multitrack and Audio Sub-group Master:
• Use channel assignment buttons to feed the post-fader signal to the desired Summing
Bus(es)
• The audio from all of the channels contributing to a summing bus will be summed at the
Sub-master
• Turn ON the corresponding Summing Bus Sub-master
• Set the level to unity gain or as needed
• The sub-master output is fed by the corresponding Bus Output connector
• Connect the Bus Output to the input of the recorder, DAW, or unused input (patching
required)
Echo Send Master:
• Use channel assignment buttons to feed the post-fader signal to the desired Summing
Bus(es)
• Turn ON the corresponding Summing Bus Sub-master
• Set the level to unity gain
• The Sub-master output is fed by the corresponding Bus Output connector
• Connect the Bus Output to the input of the device to be used
Mix Input:
• Connect the output of the desired device (effects unit, recorder, DAW, etc.) to the
Program Bus Mix Input
• This input feeds the input to the Program Bus Assignment switches on the Summing Bus
Sub-masters 1-8
• Turn the corresponding Sub-master ON
• Assign to the Program Bus
• Use the TRIM control to set the desired level
Summing Bus Multichannel Mix Outputs (LCRS, 5.1, 5.1EX, 7.1):
• Use the Program Bus for the Left and Right channels
• Select four Summing Buses for use as Center, Left Surround, Right Surround, and LFE
channels and make the appropriate assignments
o The Pan-pot may be engaged for Left and Right Surround panning
• Use the channel fader to adjust the contribution to the assigned 5.1 mix channels
• Turn ON the selected Summing Bus Sub-masters (SUM 1-8)
• Set the levels to unity gain
• The Summing Bus Sub-masters are fed by the corresponding Summing Buses
• The L/R mix outputs are fed to the L/R Program Output connectors
• The Ls, Rs, C, and LFE mix outputs are fed to the Buss Output connector
• Use addition Summing Buses if additional mix outputs are needed
• The Summing Buses and Sub-masters can also be used as additional Left and Right mix
outputs
