Page 11
System Function Display
The system function messages are displayed on the 2
nd
line of the home display. The messages
that could be displayed are shown below.
This is the normal display. Optimising is on and
using output 1 in variable power mode and
surplus generated energy will automatically be
used for water heating.
This shows that optimising is on using output 1
in threshold mode. The load connected to
output 1 will be turned on when the threshold
is reached.
This indicates that the optimising has been
turned off by the user in the set-up menu. All
surplus generated energy will be exported.
Optimising has been disabled by the system
due to the error displayed on the bottom line
of the display
Boost mode on output 1 has been activated by
pushing the boost button. The remaining boost
time is displayed.
Timer mode is enabled and output 2 is on due
to timer on-time programming.
Timer 2 ON
Boost 1 ON 58 mins
Optimising DISABLED
Threshold 1 ON
Optimising 1 ON
Apollo GEM User Manual
