Apollo Solar GEM User Manual

Page 20
User Set-up Screens
All of the Apollo GEM set-up screens are shown below.
Screen 1. Timer and optimiser enable/disable
The timer and optimiser functions can be
independently enabled or disabled.
This screen is also used to set the day and time.
Screen 2. Weekday timer on/off programming
Up to 3 on/off time pairs can be programmed.
On/off pairs do not have to be in time order.
To make a pair unused, program the start time
to 00:00
Screen 3. Weekend timer on/off programming
As for weekday programming
Screen 4. Temperature Settings
Tmr/Boost Temp sets the temperature when in
timer or boost mode.
Optimiser Temp sets the temperature when
using excess generated energy in optimiser
mode.
Screen 5. Legionella Control
Program settings for the legionella control cycle
on outputs 1 & 2
Set Legionella Cycle to "NO" to disable legionella
functions completely (default)
Legionella Cycle YES
OP1 Sat 12:00 65oC
OP2 Sun 12:00 65oC
Tmr/Boost Temp 50ºC
Optimiser Temp 60ºC
Temp set by heater
T/Stat if no sensor
Set Timer SAT-SUN
O/P 1 1 2
ON 07:30 13:00 00:00
OF 09:00 15:00 00:00
Set Timer MTWTF
O/P 1 1 1
ON 07:30 13:00 18:00
OF 09:00 14:00 20:00
Timer ENABLED
Optimiser ENABLED
Set Time Mon
14
:01
