4 Configuration
4.1 Administrative Settings
This chapter describes how to do the initial configuration of the unit such as setting
the unit IP address, changing the GUI password and setting the unit time.
4.1.1 Accessing the Web Interface
All modules in the unit are controlled via the web interface provided with the unit.
The unit management software runs on the module configured as Man Machine
Interface (MMI). Normally the MMI is installed on the module in slot 1, however any
input module can be configured as the MMI module. Only one module in the chassis
should be configured with the MMI option.
All modules with MMI are configured with a default IP address of 192.168.1.100. To
change the network settings of the device please follow the steps described below.
Connect a PC directly to the device (the Ethernet port marked “control” on the master
module – usually in slot 1) with an Ethernet cable
Set the IP address of the Ethernet adapter of the PC to a fixed address in the same
segment (e.g. 192.168.1.99). Please refer to the operating system manual for setting
the IP address on the PC.
Start an internet web-browser and type 192.168.1.100 in the address field.
The following screen will appear (exact configuration of the unit will vary):
