APPOTECH CW6632B - Audio ADDA Parameters; USB PHY Parameters; RF Analog Blocks

18 Characteristics 123
CW6632B Bluetooth 3.0 Audio Player SOC Version 1.0.0
Copyright ©2015, www.appotech.com. All Rights Reserved.
Symbol
Description
Min
Typ
Max
Units
Conditions
I
LEVEL2
Level2 current driving
24
-
-
mA
For Port1.1
18.4 Audio ADDA Parameters
Table 18-4 Audio DAC Parameters
Sym
Characteristics
Min
Typ
Max
Unit
Conditions
DAC SNR&DR
-
90
-
dB
48PIN
DAC SNR&DR
-
90
-
dB
28PIN & 20 PIN
DAC THD+N
-
-80
-
dB
10Kohm loading
PWR
AB
ClassAB AMP power output
-
-
16
mW
32ohm loading
V
PP
Maximum output voltage
-
-
2.6
V
10Kohm loading
ADC SNR/DR
93
dB
In Voice Band
ADC THD+N
89
dB
In Voice Band
18.5 USB PHY Parameters
Table 18-5 USB PHY Parameters
Sym
Characteristics
Min
Typ
Max
Unit
Conditions
RDM
PUP
DM pull-up resistor
-
120
-
KΩ
RDP
PUP
DP pull-up resistor
-
1.5
-
KΩ
RDM
PDN
DM pull-up resistor
-
15
-
KΩ
RDP
PDN
DP pull-up resistor
-
15
-
KΩ
18.6 RF Analog Blocks
Table 18-6 Frequency Synthesizer Parameters
Parameter
Condition
MIN
typ
max
Unit
Synthesizer
Synthesizer settling time
Within +/- 25 KHz accuracy
-
70
-
us
Phase Noise
Fc=2.4GHz
F=1 MHz
-
-110
-
dBc/Hz
F=2 MHz
-
-118
-
dBc/Hz
F3 MHz
-
-123
-
dBc/Hz
XTAL Oscillator
Frequency range
-
26
-
MHz
Frequency Trimming Range
6 bits
-1
-
+1
kHz
Table 18-7 Receive path Parameters
