7.2.2 Timer1 Special Function Registers
Register 7-5 TMR1CON0 – Timer1 control 0
Position
7
6
5
4
3
2
1
0
Name
T1ES
T1M
T1CPSEL
T1IS
Default
0
0
0
0
0
0
0
0
Access
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
T1ES: Timer1 Capture Edge Select
00 = CAP1 Rising Edge
01 = CAP1 Falling Edge
1X= CAP1 Rising Edge and Falling Edge
T1M: Timer1 Mode Select
00 = Timer1 is disabled
01 = Timer1 is enabled and works in Counter Mode
10 = Timer1 is enabled and works in PWM Mode
11 = Timer1 is enabled and works in Capture Mode
T1CPSEL: Timer1 capture input pin select
0 = Capture CAP1
1 = Capture IR1
T1IS: Timer1 Increase Source
000 = TMR1 Rising Edge
001 = TMR1 Falling Edge
010 = TMR1 Rising and Falling Edge
011 = External 32 KHz crystal oscillator
1xx = System clock cycle
Register 7-6 TMR1CON1 – Timer1 control 1
Position
7
6
5
4
3
2
1
0
Name
T1TPND
T1CPND
T1TIE
T1CIE
-
T1PSR
Default
0
0
0
0
-
0
0
0
Access
R/W
R/W
R/W
R/W
-
R/W
R/W
R/W
T1TPND: Timer1 over Flow Pending Bit
0 = Not Pending
1 = Pending
T1CPND: Timer1 Capture mode Pending Bit
0 = Not Pending
1 = Pending
T1TIE: Timer1 over Flow Interrupt Enable Bit
0 = Interrupt Disable
1 = Interrupt Enable
