6 General Purpose Input/Output (GPIO) 45
CW6632B Bluetooth 3.0 Audio Player SOC Version 1.0.0
Copyright ©2015, www.appotech.com. All Rights Reserved.
Pins
Func1
Func 2
Func3
Func4
Func5
Func6
Func7
Fun8
Type
P00
AUXL0
UARTRX1
SDDAT1
SPI0DIN2
A
P01
AUXR0
UARTTX1
PORTINT/WKUP0
SDDAT2
A
P02
AUXL1
SPI0DOUT1
TMR1PWM
A
P03
AUXR1
SPI0CLK1
TMR0CAP
A
P04
SPI1DOUT/DIN1
A
P05
SPI1CLK
A
P06
PORTINT/WKUP1
SPI1DIN/SPI0DIN1
TMR0CKI/TMR1CKI
IISDI0
A
P07
PORTINT/WKUP3
Ir_input
TRM1CAP
A
P10
EMIWR
C
P11
C
P12
C
P13
ADC5
IISBCLK0
B
P14
ADC2
SDDAT3
SPI0DOUT2
TMR3CAP/TMR3PWM
IISDO0
A
P15
TMR3CKI
B
P16
BTUART1TX
UARTTX0
Ir_input
TMR2CAP/TMR2PWM
IISREF
A
P17
BTUART1RX
TMR2CKI
IISWS0
B
P20
AUXL2
SDCMD
EMIDAT0
C
P21
AUXR2/ADC1
SDCLK
EMIDAT1
C
P22
ADC3/LVDIN
EMIDAT2
IISDO1
C
P23
EMIDAT3
IISDI1
C
P24
EMIDAT4
C
P25
EMIDAT5
SPI0DIN0/DOUT0
IISBCLK1
C
P26
ADC6
EMIDAT6
SPI0CLK0
IISWS1
C
P27
SDDAT0
EMIDAT7
SPI0DOUT0
C
P30
ADC4
SDCLK
SPI0CLK3
C
P31
SDCMD
SPI0DIN3
C
P32
SDDAT0
SPI0DOUT3/DIN3
C
P33
ADC0
Ir_input
32K/xosc12m
SysClk
TRM1CAP
A
P34
UARTRX0
PORTINT/WKUP2
SPI0CLK2
TMR0PWM
C
P35
MUTE
D
P36
A
P37
GPIO
B
P40
Ir_input
SPI0CLK4
A
P41
A
P42
SPI1DIN1‟
A
P43
A
P44
DACL
E
P45
DACR
E
