APPOTECH CW6632B - Page 65

6 General Purpose Input/Output (GPIO) 59
CW6632B Bluetooth 3.0 Audio Player SOC Version 1.0.0
Copyright ©2015, www.appotech.com. All Rights Reserved.
WKPIN0SEL1: wakeup pin0 select bit1
0 = control by WKPIN0SEL
1 = P30
WKPIN1SEL: wakeup pin1 select bit1
0 = P06
1 = BT_CTS
WKPIN0SEL: wakeup pin0 select bit0
0 = P01
1 = BT_CDCLK
Register 6-27 PMUXCON2 – Port Function MUX control 2
Position
7
6
5
4
3
2
1
0
Name
PMUXCON2
Default
0
0
0
0
0
0
0
0
Access
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
PMUXCON2: PORT 2 Wake up enable
0 = disable
1 = enable
Register 6-28 PMUXCON3 – Port Function MUX control 3
Position
7
6
5
4
3
2
1
0
Name
PMUXCON3
Default
0
0
0
0
0
0
0
0
Access
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
PMUXCON3: PORT 3 Wake up enable
0 = disable
1 = enable
Register 6-29 PMUXCON4 – Port Function MUX control 4
Position
7
6
5
4
3
2
1
0
Name
PMUXCON4_74
PMUXCON4_30
Default
0
0
0
0
0
0
0
0
Access
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
PMUXCON4_76: P12/P13/P16/P17 Wake up enable
0 = disable
1 = enable
PMUXCON4_30: P00/P01/P02/P03 Wake up enable
0 = disable
1 = enable
