Install the Front Rail
Tools ½ - inch Open-End Wrench
½ - inch Socket Wrench
1. Lift the front rail in place with the flat side
toward the cross tubes. Slide one end
into one leg opening: center rail between
both legs.
2. Align the rail mounting holes with each leg
bracket. Move the leg slightly left or right if
necessary. Slip a 5/6” x 1” bolt (B) into the
mounting holes on both rail ends. Add the lock
washer (C) and nut (D) to each rail mounting
bolt, HAND TIGHTEN ONLY at this point.
