Lenni – Lucey Oparation
1. Slip one
spacer (L)
onto one
serrated bolt
(K)
4. Keep the cross tubes
“square” or parallel
with the top and
bottom of the rail. Hold
the cross tube in place
as you HAND TIGHTEN
the serrated bolt.
After you start the bolt,
slip the spacer into the
rail hole.
2. The cross tube has a
threaded center hole.
Align this with the rail
mounting hole.
3. Hold the cross tube on
the inside of the rail
and start the bolt into
the threaded
mounting hole. After
you start the bolt, slip
the spacer into the rail
hole.
5. Repeat steps 1-4 for the remaining cross tubes along the rear rail. Be sure that the spacers remain
inside the rail holes as you hand tighten each serrated bolt.
