SPECIFICATIONS
MODEL E100C
Unit Weight 64 lbs�
Shipping Weight 82 lbs�
Capacity
80°F, 60% RH Conditions
100 pints per day @ 280 CFM
Power
115 VAC, Single Phase, 60Hz
6�9A operating current
Dehumidifier Inlet Air Conditions Dehumidification: 50°F – 104°F, 40°F dew point minimum
Filter MERV 8, washable
Airflow
EXTERNAL STATIC PRESSURE ("w.c.) AIRFLOW (CFM)
0�0 280
0�2 245
0�4 210
0�6* 175
*Maximum design external static pressure.
Note: Rated capacity and current draw measured at 80°F/60% RH inlet conditions at 0.0 external static pressure.
REMOVE SHIPPING BRACKET
IMPORTANT: Cut the strap securing the compressor shipping
support bracket and remove the strap, shipping bracket screws, and
bracket� See FIGURE 1�
CLIP OFF
AND REMOVE
PLASTIC STRAP
REMOVE SHIPPING
BRACKET SCREWS (2)
REMOVE
SHIPPING
BRACKET
90-1908
FIGURE 1 – REMOVE SHIPPING BRACKET
2 English
