3. TERMINOLOGY AND SYMBOLS USED IN THIS MANUAL
• OPERATING AREA:
Zone around the area where the installation procedure is being carried out and where persons may be exposed
to safety and health hazards (Attachment I, 1.1.1 - EEC Directive 89/392);
• PERSON EXPOSED TO RISKS: Any person who is wholly or partially present in a hazardous area (Attachment I, 1.1.1
- EEC Directive 89/392);
• INSTALLER: Person in charge of installing, commissioning, adjusting, maintaining, cleaning, repairing and transporting
the device (Attachment I, 1.1.1 - EEC Directive 89/392);
•
RESIDUAL HAZARD: A hazard that could not be eliminated or reduced during the design process.
Warning
!
Indicates information, instructions or procedures that can cause injury, death, or long term
health or environmental hazards if not observed correctly.
Caution
Indicates procedures or practices that can seriously damage to the machine or the product
if not carried out correctly.
Information
Provides information about particularly important matters: failure to respect these indications
may result in the guarantee being invalidated.
4. HARRIER TECHNICAL SPECIFICATIONS
4.1 INTENDED USE AND APPLICATIONS
The Harrier electro-mechanical unit is designed to operate (open and close) a barrier;
It is intended exclusively for use with vehicular traffi c.
Any other use is considered improper and therefore hazardous.
No other use is authorised by Aprimatic.
Caution
• It is forbidden to use the product for any other purpose than the intended one.
• It is forbidden to tamper with the product or modify it.
• Only APRIMATIC accessories may be used when installing the product.
4.2 TECHICAL DATA FOR AVAILABLE VERSIONS
Introductory notes / Technical specifi cations
Version E25-X25 E40-X40 E50-X50 E60-X60
Single phase power supply 230 V - 50 Hz.
Motor power Kw 0.18 0.18 0.15 0.24
Consumption A 1.4 1.4 2.7 2.0
Number of rotations slow shaft rpm 23.3 17.5 9 4.6
Number of poles 4 4 6 4
Reducer type MVF 49/P MRVF 49/P MVF 49/P MRVF 49/P
1:60 1:80 1:100 1:300
Max Torque (dynamic) Nm 40 60 95 160
Operating time sec. 1.8 2.5 5 9.5
Max. Barrier length m 2.5 4 5 6
Max barrier length with skirt m 4 5
Operating temperature °C - 15 ÷ 60
Lubrication SHELL Trivela Oil SC 320 (synthetic oil)
Use continuous
