Dual exposed shower with fixed and adjustable shower heads installation instuctions page 12
Commissioning
1. Ensure that the hot water system is at normal maximum temperature.
2. Turn the temperature control knob to the mid-blend position (with the
lever at the top of the knob).
3. Carefully unscrew the lever from the knob and set aside.
4. Remove the temperature lever grub screw and set aside.
5. Using a suitable hexagonal key, loosen the grub screw and pull the
temperature control knob clear.
6. Turn the valve on.
7. Using a digital thermometer, rotate the cartridge spline to adjust the
temperature control to the required MAXIMUM temperature setting.
We recommend the MAXIMUM outlet temperature is set to 46
O
C.
8. Turn the valve off.
9. Using a suitable tool, remove the maximum temperature stop ring.
10. Reposition the temperature stop ring ensuring the maximum temperature
stop point aligns with the markings on the temperature spline.
11. Refit the temperature control knob onto the valve with a temperature
lever fixing point in the maximum temperature position.
12. Secure the knob to the valve and refit the temperature control lever
assembly.
! If required, the flow control knob can be removed following the
above procedure.
!
THE DUAL PRODUCT RANGE IS PRE-SET TO A SAFE
MAXIMUM SHOWER TEMPERATURE. SHOULD IT BE
NECESSARY TO RESET THE MAXIMUM TEMPERATURE
POSITION, PLEASE OBSERVE THE FOLLOWING PROCEDURE.
WE RECOMMEND THE MAXIMUM OUTLET TEMPERATURE
IS SET TO 46
O
C.
