THE MIDAS PRODUCT RANGE IS PRE-SET TO A SAFE MAXIMUM SHOWER
TEMPERATURE. SHOULD IT BE NECESSARY TO RESET THE MAXIMUM TEMPERATURE
POSITION, PLEASE OBSERVE THE FOLLOWING PROCEDURE.
WE RECOMMEND THE MAXIMUM OUTLET TEMPERATURE IS SET TO 46ºC.
1. Ensure that the hot water system is at normal maximum temperature.
2. Turn the temperature control knob to the mid-blend position (with the button at the top of the knob).
3. Carefully remove the end cover cap using a small flat bladed screwdriver if necessary.
4. Remove the central fixing screw, pull the knob clear and set aside.
5. Turn the valve on.
6. Using a digital thermometer, adjust the temperature control to the required MAXIMUM temperature
setting. We recommend the MAXIMUM outlet temperature is set to 46ºC.
Adjust the temperature by small movements of the central spline hotter or colder as required. One
spline adjustment is approximately 2ºC.
If required, rotate one spline at a time and check outlet temperature.
Note: for factory settings markings are aligned, see image 1.
7. Turn the valve o.
8. Ensuring the temperature override button is pushed in, replace the knob onto the valve in the mid
blend position.
9. Secure the knob to the valve and refit the knob insert.
SHOULD UNACCEPTABLE DAMAGE TO THE TEMPERATURE KNOB END CAP OCCUR
WHEN REMOVING IT FROM THE TEMPERATURE KNOB, PLEASE CONTACT AQUALISA
CUSTOMER SERVICE ON 01959 560010 TO ARRANGE A REPLACEMENT.
.
MIDAS RANGE COMMISSIONING
Image 1.
Image 2.
32
UK
