If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA:(08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT:
Protective eyewear
Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a potentially hazardous
situation it is suggested that protective safety gear be worn or a safe work procedure be employed. If these notes and
warnings are not heeded, injury may result.
TOOL LIST FOR FITMENT:
 Torque Wrench 0-25Nm
 Sockets ¼”, 10 & 13mm, socket extension bar
and driver
 Spanners, ratchet type, 8, 10 and 13mm.
 T30 Torx Driver
 Tape measure
 150mm ruler
 Power or pneumatic drill
 Drill bits 5mm, 6.5mm, 12mm, 14mm
 12mm deep drill stops for 5mm and 6.5mm drill
bits.
 Knife
 Sharp scissors
 File or sheet metal de-burring tool
 Metal primer touch up paint
 Engineer’s scribe
 Sheet metal vice grip clamp
 Quicklock G clamp
 Centre punch
 Silicon Caulking Gun
 Neutral cure Non-Acetic Silicon
 Phillips head screwdrivers
 Flat blade screwdrivers
 Side Cutters
 Wire stripping tool
 Non-permanent marker
 Electrical tape
 Masking tape
 Plastic Squeegee
 Cleaning cloths / rags
 Angle grinder and cut off wheel
 Cable ties 6 off 450mm long (not supplied)
 Cable ties 8 off 200mm long (not supplied)
FITTING THE CANOPY IS UNDERTAKEN IN THE FOLLOWING STAGES:
1. Removing any sports bars & bed liners and sealing the tub
2. Fitting the tub mounting brackets. (Note details of fitting with bed liners refer to Section 7)
3. Fitting main seal before the canopy is fitted.
4. Fitting the canopy to the vehicle
5. Wiring of the canopy to the vehicle
6. Fitting the bed liners
7. Owner’s manual supplement
8. Fitment check list
NOTE: DURING THE INSTALLATION IT IS NECESSARY TO DRILL SOME HOLES THROUGH THE VEHICLE’S
TUB SHEET METAL. IT IS RECOMMENDED THAT THESE ARE DE-BURRED AND THE RUST
INHIBITOR THAT IS PROVIDED BE USED TO AVOID RUST & ANY SWARF LEFT OVER SHOULD BE
CLEANED FROM THE TUB.
