If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA:(08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
!! IMPORTANT !! other than specifically specified in this instruction
REQUIRED SCREW TORQUES: M6=9Nm M8=22Nm
Screw torques must be adhered to avoid warranty issues and should be checked at vehicle service intervals.
THE FITTING KIT CONSISTS OF:
Packed under the canopy are:
668PD046 Front Mount Rail
Part No
Qty
Description
1. 6174921
MAIN
CANOPY
HARDWARE
KIT
6821135
2
TUBE CONVOLUTED M7 BLK 250mm LONG
668PB014
1
1650 x 26 x 6 FOAM TAPE
665037
1
ROLL- CLEAR TAILGATE PROTECTION TAPE
30MM WIDE
6821132
2
GROMMET 3/8 ID (ONE FOR SHEET METAL
SECOND ONE USE WHEN FITTING
BEDLINER)
665076
3
BUMPON STRIP OF 5 PIECES
665505
1
RUST INHIBITOR SACHET
665044
1
PRIMER STICK
180701
1
SCOTCH LOCK (14-18 AWG)
6821134
1
FUSE HOLDER BLADE TYPE
6821273
3M
WIRE 0.75MM RED CUT 3 METRE
6821127
1
3 AMP BLADE FUSE
CR07
0.5M
7MM CONVOLUTED TUBE BLACK|(BULK)
668PB010
1 Pair
TUB SEALING BLOCK - FOAM
668PB023
1 PAIR
REAR SEALING PAD – FOAM TAPE
6151625
12
M8 x 25 TORX PAN HEAD SCREW - BLACK
