1.62) Unclip the white retainer on the back of the
plug and pull it out.
1.63) Press down on the clip remaining on the back
of the plug receptacle and disconnect the
loom. The bed liner may now be removed
from the tub
1.64) Mark out the front LH side of the bed liner on
the side that is against the vehicle tub as
shown.
Repeat this on the opposite corner in
mirror image
To Next Page
