1. SMALL PARTS BAG
Part No
Qty
Description
668PD008
2
BRACKET CENTRE TUB MOUNT
668AQ010
2
ASSY-BRACKET WELD NUT PLATE FRONT TUB MOUNT
665074
1
ROLL - SOFT FOAM 6.3MM THICK X 20MM WIDE
6151212
6
M8X1.25 BLACK NYLOC NUT
6151213
10
M6X20MM BLACK HEX HEAD SCREWS GD 8.8
4581287
2
M6 BLACK SPRING WASHERS
4584310
12
M6 X 25MM X 2.8MM THICK BLACK FLAT WASHERS
6151173
6
M6 WIZZLOCK FLANGE NUTS - BLACK
6151625
10
M8 X 25 TORX PAN HEAD SCREW - BLACK
4581303
10
M8 X 25.4MM X 3MM THICK BLACK FLAT WASHERS
4581085
6
M8 X 19MM X 1.2MM THICK BLACK FLAT WASHERS
665037
1
ROLL- CLEAR TAILGATE PROTECTION TAPE 30MM WIDE
668PB010
2
A PACK OF 2 TUB SEALING BLOCKS- FOAM
668PB006
2
PAIR OF DIE CUT BLACK STICKERS
665046
1
BRAKE LAMP BLACKOUT STICKER
668PM005
1
PAIR OF RUBBER SELF-ADHESIVE TUB CORNER SEAL
BRIDGES
668PJ012
1
ELECTRICAL LOOM- VEHICLE FORD RANGER HARNESS
668PJ015
1
ELECTRICAL RELAY BOX
665505
1
RUST INHIBITOR SACHET
2. TUB MOUNT BRACKETS IN
CARTON
668AQ001R
1
RH- REAR TUB MOUNTING BRACKET
668AQ001L
1
LH- REAR TUB MOUNTING BRACKET
668PD027R
1
RH- FRONT CORNER TUB MOUNTING BRACKET
668PD027L
1
LH- FRONT CORNER TUB MOUNTING BRACKET
NOTE :- IF FITTING A CANOPY TO A FORD RANGER PXII XL & XLS OR PXIII MODEL TO
INCLUDE RAPTOR, YOU MUST PURCHASE THE 4740020 STOP LIGHT COVER KIT
SEPERATELY
