2.1. Machine description
The labelling machine is an automatic application machine t for the solution of any labelling problem. This
machine is an high precision device that enables, by means of a wide range of applicators, to label any kind of
product (bottles, tanks) ensuring high quality results.
The machine is pretty compact an modular, in order to enhance its insertion and moving on already existing
lines.
The whole essential functions of the labelling machine are included in a single control unit (it depends if the
labelling machine is inserted in a system or not), or in a control panel. Please refer to the related section of this
manual for the description of these functions.
The labelling machine can be equipped with different kind of applicators according to the type of product to
label, to the related position of the product according to the labelling machine and the position of the label on
the product.
The different kind of applicators are described in the related manuals.
2.1.1.Principal functional groups of the labeller
A. Reel holders.
B. Rewindind group
C. Transport group
D. Application device
E. Sensor reading labels
F. Control unit
2.2. foreseen use of the labelling machine
The labelling machine is used to work with label reels with a denite size.
The silicon support band of the labels is unwound by the reel and transported on the blade which allows the
lm removal. The silicon band recovery is carried on by means of the rewinder..
ATTENTION! ARCA Etichette S.p.A. declines any responsibility for damages to persons or things deriving
from a wrong use of the machine. Carefully follow the instructions given in this manual for a correct and safe
use of the machine.
