Arcam AVR300 Service Manual

- 67 -
AVR300 SURROUND SOUND RECEIVER
R416,R543,R547,R553,R557,R563,R567,
R573,R577
4720-223J-J RMG 1/10W 22K 5% 0805
R530,R531 4720-242A-J RMG 1/10W 2.4K 1% 0805
R409,R478 4720-330J-J RMG 1/10W 33R 5% 0805
R542,R548,R552,R558,R562,R568,R572, R578 4720-332J-J RMG 1/10W 3.3K 5% 0805
R425,R429,R433,R437,R441,R445,R449,
R583,R599
4720-392J-J RMG 1/10W 3.9K 5% 0805
R474,R481,R488,R495,R502,R509,R516 4720-432J-J RMG 1/10W 4.3K 5% 0805
R419,R420,R422,R423,R427,R431,R435,
R439,R443,R447,R451,R452,R455,R458,
R461,R464,R467,R470,R473,R480,R487,
R494,R501,R508,R515,R522
4720-472J-J RMG 1/10W 4.7K 5% 0805
R635 4720-473J-J RMG 1/10W 47K 5% 0805
R401,R402,R403,R404,R406,R407,R600, R601 4720-512A-J RMG 1/10W 5.1K 1% 0805
R410,R411,R424,R428,R432,R436,R440, R444,
R448
4720-512J-J RMG 1/10W 5.1K 5% 0805
R541,R545,R551,R555,R561,R565,R571, R575 4720-682J-J RMG 1/10W 6.8K 5% 0805
R523 4720-752J-J RMG 1/10W 7.5K 5% 0805
IC
U405 3130-2020-2 IC 7805 REG 5V
U406,U407,U408,U409,U410,U411,U412,
U413,U414,U415,U416,U417
3131-4850-0 IC NJM5532M JRC (SMD)
U625 3132-0390-0 IC B1117N-3.3V 33M142
U418,U419,U420,U421,U422,U423 3132-0420-0 IC 74HC4052 SO-16
U403,U404 3132-0440-0 IC 74HC4053 SO-16
U401 3132-0980-0 IC WM8770 8CH VOL CONTOL
HEATSINKS
U405C 5400-0831-0 HEATSINK
WIRE
P105B 7012-6677-0 CONN WIRE 8P P=2.5 28AWG
P101B 7012-6678-0 CONN WIRE 6P P=2.5 28AWG
SP401 7012-6765-1 CONN WIRE UL1015 14AWG
SP402 7012-6825-1 CONN WIRE UL1015 22AWG
SCREW
U405A 2954-2606-0000 SCREWS BT 2.6X6
U405B 2954-3008-0000 TAPPING 3X8MM B-TITE
PC BOARD
4000 1725-696A-0001 PCB MULTI/VIDEO AVR300
Reference No. Part No. Description
