Arcam AVR300 Service Manual

AVR300 SURROUND SOUND RECEIVER
- 68 -
PHONE ASSY
PC BOARD
PCB-AL050C-PHO PCB ASSY PHONE AL050C
CAPACITORS
C1,C2 150F-102K-2-FC CC 50V 1000pF 10% AT 3.5
DIODES
D880 4804-1480-2 DIODE 1N4148 AT
JACKS/SOCKETS
JA1 2113-1733-0 PHONE JACK 6312-03-070
RELAY
RE880 4500-0600-1 RELAY BP-9 9VDC BESTAR
TRANSISTOR
Q880 485C-123J-5 TR DTC123JSA ROHM
WIRE
P1002B 7012-6675-0 CONN WIRE 2P P=2.5 26AWG
P860B 7012-6685-0 CONN WIRE 4P P=2.5 26AWG
P300A 7012-6761-0 CONN WIRE 3P P=2.5 380MM
PC BOARD
8010 1725-694A-0001 PCB KEY/TUN/PSU/PHONE
P-MAIN ASSY
PC BOARD
PCB-AL050C-PMAIN PCB ASSY P-MAIN AL050C
CAPACITORS
C824,C825,C826,C827,C828,C829,C830 150F-102K-2-FC CC 50V 1000pF 10% AT 3.5
C831,C832,C833,C834,C835,C836,C837, C875,
C876,C877,C878,C879,C880,C881
150F-104K-2-FC CC 50V 0.1UF 10% AT
C820,C821,C822,C823 8910-0492-0 CE 63V 12000uF 20% RL
DIODES
C831,C832,C833,C834,C835,C836,C837, C875,
C876,C877,C878,C879,
4804-0040-2 DIODE IN4004 AT
WAFERS/SOCKETS
N801,N802,N803,N804,N805,N806,N807,
N808,N809,N810
2101-1231-0 SPADE TERMINAL 6.3X0.8
P804A 2101-1621-0 WAFER (PCB/PCB) 10P P2.0
Reference No. Part No. Description
