Arcam AVR300 Service Manual

- 69 -
AVR300 SURROUND SOUND RECEIVER
P103B,P105B 2101-1811-0 8P PIN CONNECTOR P=3.96
P806A 2102-041S-004 4P ST.WAFER
JACKS/SOCKETS
SP801,SP803,SP804 2113-1770-0 TERMINAL SPEAKER 4P
SP802 2113-1771-0 TERMINAL SPEAKER 2P
COILS
L801,L802,L803,L804,L805,L806,L807 1804-0540-0 SPRING COIL 1MH
RELAY
RE805,RE806 4500-0580-0 RELAY 24V 30A DC 2P1T-6P
RE802 4500-0900-0 RELAY 24VDC,250VAC,10A
RE801,RE803,RE804 4500-0910-0 RELAY 24VDC,125VA,3A
TRANSISTOR
Q822,Q823,Q824 485C-123J-5 TR DTC123JSA ROHM
RESISTOR
R820,R821,R822,R823,R824,R825,R826, R827,
R828,R829,R830,R831,R832,R833
4718-100J-2 RMF 1W 10R 5% AT
R851,R852 4718-391J-2-X RMF 1W 390R 5% AT
WIRE
P803A 7012-6676-0 CONN WIRE 8P P=2.5 26AWG
PC BOARD
1725-697A-0001 PCB PMAIN AVR300 E
MISCELLANEOUS
RE801,RE802,RE803,RE804 4157-0491-0 RUBBER PAD 15X6MM
POWER ASSY
PC BOARD
PCB-AL050C-POWER PCB ASSY POWER AL050C
WAFERS/SOCKETS
PD101,PD102,PD103 2101-1231-0 SPADE TERMINAL 6.3X0.8
JACKS/SOCKETS
JK101 2113-1345-0 AC INLET (PCB MOUNT)
PC BOARD
1020 1725-695A-0001 PCB AMP1/AMP2/SW/RECT/
Reference No. Part No. Description

Arcam AVR300 Specifications

General

Brand	Arcam
Model	AVR300
Category	Receiver
Language	English
