AVR300 SURROUND SOUND RECEIVER
- 70 -
POWER SUPPLY ASSY
PC BOARD
* CE BLACK / CE SILVER PCB-AL050C-PSU PCB ASSY POWER SUPPLY
* UL BLACK / UL SILVER PCB-AL052C-PSU PCB ASSY POWER SUPPLY
CAPACITORS
C874 150F-104K-2-FC CC 50V 0.1UF 10% AT
C873 157D-477M-K-OVI CE 16V 470UF 20% RLT
C871 157E-227M-K-OVI CE 25V 220UF 20% RLT
C872 8910-0091-0 CC 400V 0.01UF +-20% RL
DIODES
D870,D871,D872,D873 4804-0040-2 DIODE IN4004 AT
D874 4804-1480-2 DIODE 1N4148 AT
WAFERS/SOCKETS
DP801 2101-1231-0 SPADE TERMINAL 6.3X0.8
P874,P875 2101-1432-0 WAFER 2P P7.92 JAPAN
P870 2101-1519-0 SOCKET 5P P=3.96
P804B 2101-1801-0 SOCKET (PCB/PCB) 10P
RELAY
RE870 4500-0590-0 RELAY 12VPC 250VAC 20A
THERMISTOR
J34 *CE BLACK / CE SILVER 5202-0009-0 NTC THERMISTER SCK-0512
TRANSISTOR
Q901 4860-2270-5 TR 9014C SAMSUNG
RESISTOR
R870 4711-302A-2 RMF 1/8W 3K 1% AT
R871 4711-472A-2 RMF 1/8W 4.7K 1% AT
R872 4717-2R2J-2-F RMF 1/2W 2.2R 5% AT
R873 4717-335J-2-S RMF 1/2W 3.3M 5% AT UL
TRANSFORMER
T870 1806-2501-0 EI-35 TRANSFORMER GTP750
SWITCH
SW870 5200-3281-0-06 SW COMAX
FUSE
F871 5120-0058-0 FUSE T8A/250V 5X20MM UL
Reference No. Part No. Description
To Next Page
