Arcam AVR300 Service Manual

- 71 -
AVR300 SURROUND SOUND RECEIVER
F870 5120-0506-0 FUSE T12.5A 250V UR
WIRE
P873 7012-6737-0 CONN WIRE UL1672 18AWG
P873 7012-6738-0 CONN WIRE UL1672 18AWG
PC BOARD
8000 1725-694A-0001 PCB KEY/TUN/PSU/PHONE
MISCELLANEOUS
F870,F871 4132-1011-0 FUSE HOLDER
NTC1 *UL BLACK / UL SILVER 8910-0275-0 THERMAL NTC 30A 1 ohm
RECTIFIER ASSY
PC BOARD
PCB-AL050C-RECT PCB ASSY RECTIFIER
CAPACITORS
C812 153R-224K-5-Y1 CM 250V 0.22uF 10% RL
DIODES
BR101 4840-8630-0 DIODE BRIDGE RECTIFIER
WIRE
N815A 7012-6741-0 CONN WIRE UL1015 14AWG
N816A 7012-6742-0 CONN WIRE UL1015 14AWG
N817A,N818A 7012-6743-0 CONN WIRE UL1015 14AWG
PC BOARD
1000 1725-695A-0001 PCB AMP1/AMP2/SW/RECT/
RS232 ASSY
PC BOARD
PCB-AL050C-RS232 PCB ASSY RS232 AL050C
CAPACITORS
C237,C249 150F-100J-J-BD CC 50V 10pF 5% 0805 1.2x
C214,C232,C233,C240,C241,C244,C245, C250,
C251,C252,C253
150F-104K-J-BD CC 50V 0.1uF 10% 0805
C234,C235,C246,C247 150F-151K-J-BD CC 50V 150pF 10% 0805 1.
C236,C248 150F-681K-J-BD CC 50V 680pF 10% 0805 1.
C202,C204 154B-476K-3-CF CT 6.3V 47U 10% SMD 85C
C222,C224,C226,C228 157D-106M-K-GII CE 16V 10UF 20% RLT 4X5
Reference No. Part No. Description
